Electrical Requirement | 380/440v 50Hz 3Ph N+Earth |
380/440v 50Hz 3Ph N+Earth | 7 kVA |
Circuit Protection | 500mA RCD |
Pneumatic Requirement | 6 Bar minimum dry clean air |
Wrapping Materials | OPP or similar |
Pack Size (Guide Only) | Maximum Width: 200 mm Maximum Height: 180 mm (dependent on application) Max Sealing Width: 280 NB. The Max bag height is determined by the required bag width. |
Reel Diameter (mm) | 300 |
Core Diameter (mm) | 75 |
Width (mm) | 450 – 650 |
Machine Speed (ppm) | 20 – 400 (dependent upon application) |
Noise Emission (dB) | Less than 70 at 1m, 1.6m above floor |
Approximate Machine Dimensions | Length (m): 5.5 Width (m): 1.2 Height (m): 1.6 Machine Weight (kg): 1500 |
Redpack Packaging Machinery designs and manufactures Flow Wrapping and Packaging Machinery. Our markets include industries such as fresh produce, pharmaceuticals, snack foods, household products, bakery, greeting cards, gifts and toys, etc. With a brand stretching back over 35 years our flow wrapping design follows tried and tested techniques. Despite this, each application brings its own unique requirements for custom-designed features.
Our goal is to provide fresh produce packers and shippers with flexible packaging solutions that not only achieve cost-savings through operational efficiencies, but also positively affect the bottom line with increased demand from retail buyers.
